Precast Mold Vibration Motors

Scope of application	• In tunnel formwork • In columns and beams • Concrete pipe • In pre-stressed concrete molds • On Vibration Tables • In all heavily reinforced Mold
Technicial Specifications	Thanks to the possibility of operating the vibrators at different frequencies, they work away from the resonance frequency of the structure to which they are applied; so there is no possibility of damaging the body. It can be adjusted to generate different centrifugal forces to achieve the perfect configuration according to the concrete type. The result will be excellent compaction, both structurally and aesthetically. • Usage cycle: S2 continuous • Multi-voltage: 3ph 42V – 3ph 230/440V (* tolerance ± 10%) • Fixed frequency: 50Hz and 200Hz • Operating temperature: -20°C / +40°C • Material: GGG40 ductile iron
Advantages	• Durable Design • Easy setup • Different supply voltages for use on a global scale
Certificates	• CE: EU regulations and subsequent amendments: 2006/42 / CE – 2006/95 / CE; • IEC: Conformity verified according to IEC 60034 standard documents)
Accessories	• Supply Cable • Support
Industries	• Building and Construction Industry

Type	Size	Phase	Voltage ( V )	Frequency (Hz)	Current (A)	Input Power (kW)	rpm	Centrifugal Force (Kg)	Centrifugal Force (KN)	Weight (Kg)
KVM-PSV 70/1	01	3	42 / 48	200	15	0,92	12000	2580	25,310	20,4
KVM-PSV 70/2	01	3	42 / 48	150	15	0,92	9000	1815	17,805	20,4
KVM-PSV 70/3	01	3	42 / 48	200	15	0,92	6000	1130	11,085	20,4
KVM-PSV 80/2	01	3	42 / 48	150	25	1,80	9000	2185	21,435	20,6
KVM-PSV 80/3	01	3	42 / 48	200	23,5	1,70	6000	1525	14,960	20,6
