Pneumatic Vibration Motors
KVM-PV Series
UNI PV Series Vibration Motors are pneumatic (air) vibration motors that provide air pressure between 4 - 8 bar and centrifugal force between 69 kgf and 161 kgf in the range of 4000 - 9000 rpm. UNI KVM/PV Series Vibration Motors have the IP65 protection class.
Technicial Specifications |
Operates with compressed air 4 - 8 bar |
Certificates |
• IP 65 |
Applications |
• Vibrating Floors for Silos |
Industries |
••Building and Construction Sector |
II 2D Ex tb IIIB T 120°C Db - IP 66
| Rotations | Per | Munite - | Centrifugal | Force - | Air | Consumption | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | 4 bar | 5 bar | 6 bar | 7 bar | 8 bar | Weight [kg] |
||||||||||
| rpm | S.K C.F [ kg/f] | Cons. [m³/dk] | rpm | S.K C.F [kg/f] | Cons. [m³/dk] | rpm | S.K C.F [kg/f] | Cons. [m³/dk] | rpm | S.K C.F [kg/f] | Cons. [m³/dk] | rpm | S.K C.F [kg/f] | S.K C.F [kg/f] | ||
| KVM-PV-03-001 | 6600 | 69 | 0,4 | 7200 | 82 | 0,54 | 7900 | 98 | 0,64 | 8500 | 114 | 0,71 | 9000 | 128 | 0,86 | 1,9 |
| KVM-PV-04-001 | 4000 | 72 | 0,53 | 4500 | 91 | 0,64 | 5100 | 117 | 0,73 | 5600 | 141 | 0,86 | 6000 | 161 | 1,00 | 3,0 |
(*) Working moment = 2x static moment
